The envelope

What travels with a message besides its body: identity, causation, and the counters the retry engine keeps. It is the one thing every AceMQ library must agree on exactly, in every language, or two services stop understanding each other.

The headers

Note the two timestamps are encoded differently — first-seen is an integer, replayed-at is a string. That is not an inconsistency to tidy up in a port. It is the contract, and a port that "fixes" it produces messages Java cannot read.

acemq- is defined but not reserved

The three replay stamps do not carry the x-acemq- prefix, and neither do acemq-reply-to or acemq-routing-slip. They are written by a pattern rather than by the engine, and they have to reach the handler: a header in the reserved namespace is stripped on consume, which for these would mean writing them and finding them gone. AceHeaders.SharedPrefix names this namespace, and AceHeaders.IsAceHeader deliberately does not match it.

These three changed spelling after 0.5.0. Up to and including that release this library wrote x-acemq-replayed-from, x-acemq-replayed-at and x-acemq-replay-count — the reserved namespace, which every AceMQ library including this one strips before a handler sees it. A message a .NET operator replayed therefore reached a Java, Go, Python or Ruby handler with its provenance silently removed, and reached a .NET handler the same way. Java made the same move in 0.5.0 and was the second-to-last to make it. Anything matching on the old names — a shovel policy, a dashboard, a firehose consumer — needs the new ones. The old spelling is still read, so a message a 0.5.0 service replayed keeps its replay count when a newer service replays it again; it is never written.

x-acemq- is reserved

A header carrying that prefix belongs to the engine. It is materialised onto the envelope if this version knows it, and dropped from the application's headers either way.

Use your own namespace — x-yourcompany- — for anything that must survive the round trip. In this library, writing into the reserved namespace throws at the call site rather than vanishing in transit:

Envelope.Of("t").Header("x-acemq-id", "mine");   // ArgumentException

Java drops it silently on consume. Failing early is kinder than a header that disappears with nothing reporting the loss.

The defaults are contract, not convenience

Generated fixtures pinned these. Every one would have been a guess if transcribed from prose:

The AMQP messageId property also mirrors x-acemq-id.

The claim

x-acemq-claim is an optional field for a message whose payload is somewhere else and is named here — a URI, a bucket key, whatever the two ends have agreed:

var outgoing = Envelope.Of("order.placed")
    .Claim("s3://payloads/2026/09/A-1")
    .Build();

It reads back as message.Envelope.Claim, survives every retry and every hop, and can be replaced on a copy with envelope.WithClaim(...) the way Ruby's envelope.with(claim:) does. The engine never reads it and never writes it — it is the application's field, carried in the engine's namespace so that it cannot be mistaken for an application header and so that all five libraries agree on the spelling.

It is not the claim-check pattern. ClaimCheckCodec is a different answer to a related question: it frames the body itself — a marker byte, then the key — so a message either is a claim check or is not, and no header is involved. See serialization. This is a field a message may carry alongside a body it already has, and the two are usable together or separately.

This field is new here. Python and Ruby have carried claim as part of the envelope since their first release. This library reserved the name and materialised nothing, so a claim a Python or Ruby publisher set was dropped on the way in, like every other reserved header a version does not understand — silently, with nothing reporting the loss.

How this is kept honest

tests/AceMq.Amqp.Tests/fixtures/envelope-fixtures.json is generated, never written. A program publishes through acemq-java-amqp and pulls the message back at the transport level — the only place the engine's own headers are still visible, since the consumer API strips them by design.

The C# tests then assert against those bytes, in EnvelopeConformanceTests.

The generator lives in the Java repository's own test suite, so CI regenerates the fixtures on every change and fails when they differ from what is committed. That turns "the port drifted" from something a customer finds into a red build on the commit that caused it.

A second fixture, tests/AceMq.Amqp.Tests/fixtures/contract-fixtures.json, pins the behaviour either side of the wire rather than the wire itself: the retry schedule, the queue names, the rung arguments and the declared topology. It is generated the same way, carried byte-identically by all five libraries, and asserted in ContractConformanceTests. ../scripts/check-fixtures.sh compares every copy and fails on a single changed character. See Testing for what it pins and where this library still disagrees with it.
